強力塑膠PE水塔 規格尺寸表 (單位:公分)
| 品名 |
直徑
|
附蓋高度 | H1 | H2 | 蓋內徑 | 等級B厚度 m/m |
等級A厚度 m/m |
標準口徑 |
| UL-30000L | 300 | 505 | 60 | 445 | 64 | 24 | 22 | 3″ |
| UL-25000L | 286 | 475 | 45 | 430 | 64 | 22 | 18 | 3″ |
| UL-20000L | 271 | 455 | 35 | 420 | 50 | 15 | 2″ | |
| PT-15000L | 258 | 354 | 39 | 315 | 50 | 14 | 2″ | |
| PT-10000L | 227 | 313 | 48 | 265 | 50 | 12 | 10 | 2″ |
| PT-6000L | 195 | 258 | 53 | 205 | 50 | 11 | 9 | 2″ |
| UL-5000L | 190 | 227 | 45 | 182 | 50 | 11 | 9 | 2″ |
| PT-4500L | 175 | 244 | 47 | 197 | 50 | 10 | 8.5 | 2″ |
| PT-3000L | 161 | 213 | 46 | 167 | 50 | 10 | 8 | 2″ |
| UL-2000L | 133 | 182 | 32 | 150 | 40 | 10 | 8 | 2″ |
| PT-2000L | 129 | 190 | 40 | 150 | 40 | 10 | 8 | 2″ |
| PT-1500L | 123 | 172 | 41 | 131 | 40 | 10 | 7 | 1 1/2″ |
| PT-1000L | 110 | 142 | 36 | 106 | 40 | 6 | 5 | 1″ |
| PT-500L | 82 | 120 | 27 | 93 | 40 | 4.5 | 4 | 3/4″ |
| PT-250L | 65 | 100 | 24 | 76 | 33 | 4 | 3.5 | 3/4″ |
| WT-750L | 109 | 113 | 40 | 4.5 | 4 | 1″ | ||
| FT-750L | 109 | 95 | 12 | 83 | 58 | 4.5 | 1″ | |
| BC-1000L | 125 | 155 | 40 | 2″ | ||||
| BC-3000L | 176 | 228 | 40 | 2″ | ||||
| BC-6000L | 208 | 265 | 40 | 2″ |
